DAB+ Digital Radio On-Glass Windscreen Aerial

Thumbnail Filmstrip of DAB+ Digital Radio On-Glass Windscreen Aerial Images

    Purchase DAB+ Digital Radio On-Glass Windscreen Aerial

    DAB+ Digital Radio On-Glass Windscreen Aerial

    $55.00 each
    SKU: dynavin-dab-antenna-on-glass
    Brand: Dynavin
    Quantity in Basket:  None

    256-Bit SSL Secure Checkout



    Stock Status: Local stock - dispatches in 1-2 business days.
    Warranty: Australian warranty, expert advice & tech support.
    Shipping: Regular or express, plus tracked options at checkout.
    Fulfilment: Shipped from Australia by us, a 100% local business.
    Questions? Call or email us - see our contact page & FAQ.
    - options & final combined price at checkout.

    On-Glass Digital Radio Amplified Aerial / Antenna

    This aerial allows you to receive Digital Audio Broadcast (DAB / DAB+) stations. It plugs into the DAB input on the radio. The radio must be capable of receiving digital radio or it will not work. Works with Dynavin, RetroSound and many other digital radios. It mounts onto the inside of the front windscreen of the vehicle. This is the same aerial that is supplied with the Dynavin DS-DAB tuner module.

    Details:

    • On-glass adhesive active indoor aerial designed for car radios.
    • SMBf (female) connector with separate power feed wire.
    • Integrated amplifier to improve reception gain.
    • Designed for easy, drill-free fitting.
    • An internal aerial avoids issues like car wash damage, theft and vandalism associated with external aerials.

    Connection:

    • The gold SMB plug pushes onto the DAB aerial socket of the radio or tuner.
    • The red wire requires 12V DC power, usually from the remote output of the installed radio.
    • On Dynavin DS units, the remote output wire is usually labelled AMP-CON and coloured blue.

    Mounting Tips:

    • Mount the aerial on the passenger side of the windscreen, well clear of the driver's view of the road.
    • Test it first in various positions using a temporary mounting (such as removable tape) to ensure a good signal. Once stuck, it cannot be removed without damaging the film.
    • Clean the glass, then peel and stick. Fit in mild weather only.
    • The earth foil sticks to the metal of the A pillar. The paint does not need to be removed.
    • Metallic glass tint can affect reception.
    • Route the cable down the A pillar trim, taking care around airbags and other vehicle systems.

    Dimensions (Approx.):

    • Length of aerial wire strip: 163mm
    • Width of aerial wire strip: 66mm
    • Earth foil: 47 x 42mm
    • Housing: 49 x 28mm
    • Cable: 295cm
