SKU: V-2394-SL87FS SL 87 FS - 8 Ohm

Visaton Speaker Driver - SL 87 FS - 8 Ohm Fullrange Speaker
Art. No. 2394

Characteristics and Sound Properties
8 cm (3.3") full-range speaker with plastic cone and ferrite magnet. Very flat design, optimised for good voice and signal quality in public transport.

Attributes

• Meets railway standards in accordance to EN 50155 for environmental testing
• cold
• dry heat
• damp heat
• vibration and mech. shock according to DIN EN 61373
• fire protection according to EN 45545

Technical Specifications

Rated power	10 W
Nominal impedance Z	8 Ohm
Frequency response	100–17000 Hz
Mean sound pressure level	85 dB (1W/1m)
Excursion limit	±2.0mm
Resonance frequency fs	185 Hz
Height of front pole-plate	3 mm
Voice coil diameter	21 mm
Height of winding	4.5 mm
Net weight	0.24kg
Connections	4.8 x 0.5 mm / 2.8 x 0.5 mm
Protective System	IP 54 *)
Temperature range	-40...85°C

*) for front side when built into a sealed enclosure (gluing of the loudspeaker and a front cover (grille) might be necessary)
