SL 83 - 4 Ohm

Thumbnail Filmstrip of SL 83 - 4 Ohm Images

    Purchase SL 83 - 4 Ohm

    SKU: V-2278-SL83 SL 83 - 4 Ohm

    $42.00 each - special order
    Brand: Visaton
    Quantity in Basket:  None







    Visaton Speaker Driver - SL 83 - 4 Ohm Fullrange Speaker
    Art. No. 2278

    Characteristics and Sound Properties
    8 cm (3.3") full-range speaker with plastic cone and ferrite magnet optimized for demanding environmental conditions.

    Typical applications:
    - AVAS Systems
    - Column speakers

    Technical Specifications

    Rated power 8 W
    Nominal impedance Z 4 Ohm
    Frequency response 130–16000 Hz
    Mean sound pressure level 88 dB (1W/1m)
    Resonance frequency fs 250 Hz
    Height of front pole-plate 3 mm
    Voice coil diameter 16.5 mm
    Height of winding 4.6 mm
    Cutout diameter 72 mm
    Net weight 0.252 kg
    Connections 4.8 x 0.8 mm
    2.8 x 0.8 mm
    Protective system IP X5
    IP X7
    Temperature range -40 ... +105°C

    IP X5 IP X7  -40 to 105C
