Dynavin BMW 5 Series E39 and Range Rover Infotainment Upgrade System

Dynavin DS-E39 BMW E39 5 Series 1995-2004 Slim

Car radio system with a 7 inch capacitive touchscreen, both wired and wireless Apple CarPlay, wired and wireless Android Auto, and Bluetooth. Optional DAB+ is available with the DS-DAB tuner. Designed to fit right in, no extra trims or interfaces are needed!

Suitable for the following vehicles (Please check with us if any doubt as vehicle year and model can overlap):

• 5 Series BMW E39 12/1995-2004
• Land Rover Range Rover L322 (Range Rover III / Vogue) 2002-2004, with the Business or Professional radio

These units are ideal as a direct replacement of your existing radio system in your car. Designed to fit like the original unit and integrate as far as possible with the vehicle, but with many enhanced and new features plus integration with steering wheel controls and factory parking sensors. Dynavin car infotainment systems are a perfect upgrade to bring your car up-to-date with the latest technology at a reasonable price.

Features:

• Premium 7" / 16:9 LCD capacitive touchscreen display (1024 x 600 resolution) with an anti-reflection display.
• Apple CarPlay and Android Auto are built in as standard and work both wired and wirelessly. Wireless screen mirroring is also available (where compatible with your phone).
• CANBUS integration for steering wheel controls and parking sensor display, depending on vehicle.
• Bluetooth for audio streaming and hands-free phone calls via your smartphone. External compact dual digital microphone included.
• FM RDS tuner with DSP noise masking, and AM tuner.
• Optional DS-DAB tuner for DAB+, with automatic switching between DAB+ and FM (Seamless Blending).
• Integrated sound DSP processor with 16-band EQ and time correction, plus vehicle specific sound profiles professionally tuned to your exact car model. No manual calibration needed.
• Works with the original DSP sound system and retains the original amplifier.
• Multimedia playback via USB.
• Reverse camera ready; compatible with aftermarket reverse cameras, and supports factory cameras where fitted.
• Includes installation cable set, including an extension cable.

Specifications:

General

• Apple CarPlay / Android Auto, wired and wireless
• FM RDS / AM radio tuner, with optional DAB+ via the DS-DAB tuner
• Bluetooth phone and music streaming
• Maximum output power: 4 x 45W
• 5 pre-outs (Front / Rear / Subwoofer)
• CANBUS integration
• Supports AHD / NTSC / PAL camera inputs, with guideline adjustment
• Reverse camera display automatic, with fast boot-up
• Auto dimmer
• Firmware updatable
• Engine start-stop unaffected
• Menu languages: English / German / French / Spanish / Portuguese / Dutch / Italian / Polish / Danish / Czech / Finnish

Works with Wireless or Wired Apple CarPlay
With Apple CarPlay, iPhone users have an incredibly intuitive solution on board to make calls, use maps, listen to music and use messages with just a word or the touch of a button. You can enjoy Spotify, Internet radio or podcasts while still fully concentrating on the traffic where supported and compatible with your phone. Apple CarPlay and wireless Apple CarPlay are included as standard.

Works with Wireless or Wired Android Auto
With Android Auto, Android users have an incredibly intuitive solution to make calls, use maps, listen to music and use messages with just a word or the touch of a button. Android Auto and wireless Android Auto are included as standard. The wireless Android Auto feature does not guarantee compatibility with all Android phones.

Options (selection options when purchasing above, or you can buy later):

• DS-DAB Tuner: DAB+ tuner box for Dynavin Slim radios, enabling DAB / DAB+ reception, Service Following and Seamless Blending between DAB+ and FM. The DAB antenna is included.
• Reverse Camera: High-Definition reverse camera

Screen

• Display: 7-inch
• Resolution 1024 x 600 pixels (RGB)
• Capacitive touch screen
• Anti-reflection display
• Working system: TFT Active Matrix
• Active area: 153.6 (H) x 86.64 (V) mm
• Auto dimmer setting

Bluetooth

• Integrated Bluetooth module with -95dBm sensitivity and excellent anti-interference performance
• Phonebook synchronisation with 1000 entries (PBAP), with automatic phonebook transfer
• Hands-free calls via HFP
• Music streaming via A2DP, with song title, lyrics, composer and vocalist display
• Separate profile connection for hands-free and music streaming
• Supports dashboard display for caller alerts
• Supports saving pairing information for multiple phones
• Device name display
• Call list: dialled number / received calls / missed calls
• Speech volume setting: adjustable for incoming and outgoing calls
• Microphone gain adjustable
• Display of the GSM signal strength
• Display of the battery charge level

USB

• Audio playback (supported formats: AAC / MP3 / APE / OGG / FLAC / WAV / OPUS / AMR / TS)
• Video playback
• Memory playback progress
• Supports dashboard display of songs / composers
• Steering wheel control of track up / down and volume
• Supports up to 256 GB USB storage device

Sound Tuning

• Maximum output power: 4 x 45W
• Equaliser presets: Pop, Rock, Classical
• 16-band parametric equaliser
• Adjustable subwoofer level
• Fader and balance, set by dragging the crosshair on the touchscreen
• Digital time correction
• Source setting, so the volume does not jump when you switch between sources
• Adjustable volume attenuation when parked
• Adjustable maximum power-on volume
• Car specific sound setup file can be downloaded from flex.dynavin.com

AM / FM Radio

• FM frequency range: 87.5 - 108.0 MHz
• AM frequency range: 530 - 1710 kHz
• With left and right stereo channels
• FM utility sensitivity: 5-6dB, FM stop sensitivity: 22dB
• AM stop sensitivity: 21dB
• Signal to noise ratio: 56dB
• RDS functions: AF, TA, broadcast text
• Automatic station tracking function
• High Cut high frequency attenuation function
• Support for changing FM / AM memory station pictures
• Optional radio antenna power on / off

DAB+ (Optional, via the DS-DAB Tuner, features listed where supported by the broadcaster)

• DAB / DAB+ reception via the optional DS-DAB tuner
• DAB+ to DAB+ service following
• Seamless Blending (automatic switching between DAB+ and FM)
• SLS (Slideshow Service)
• DLS (Dynamic Label Service)
• Radio VIS (station cover on your radio display)
• Windscreen mounted DAB antenna included with the DS-DAB tuner.
• Reception quality can vary depending on the vehicle and other installed electronic devices.

Steering Wheel Control
The Dynavin system communicates with the multifunction steering wheel of your vehicle. This allows you to control volume, telephone, track search (forwards / backwards) and other functions as usual. When a smartphone is connected to the system, you can even activate voice control such as 'Siri' or 'Google Assistant' via the steering wheel.

Parking Sensors - Optical Parking System (OPS)
If your vehicle is equipped with factory parking sensors, this feature remains when you upgrade to the Dynavin system. Visual parking assist works with the acoustic parking assist to support the driver and detect obstacles in front of or behind the vehicle. The position of the obstacle is shown graphically on the display, including the 4-side sensors in addition to the front and rear sensors.

Reverse Camera
If your vehicle is equipped with a rear view camera, you can continue to use this convenient feature when you upgrade to Dynavin. The unit also supports aftermarket reverse cameras, with AHD / NTSC / PAL camera inputs and adjustable guidelines. A reverse input cable is included (camera optional).

Works with the Original DSP Sound System
The Dynavin is compatible with the original DSP sound system. It retains the original car amplifier, so you can enjoy excellent sound quality even after installing the Dynavin radio.

Slim Digital Microphone
The dual digital microphone uses a unique noise reduction algorithm that ensures excellent call voice quality. It is compact and becomes virtually invisible after installation, making it easy to install in all types of vehicles.

Supplied Parts

• Main unit with LCD
• Radio wiring harness
• Extension cable (front to rear)
• USB extension cable
• Dual digital microphone
• Reverse input cable (camera optional)
• Antenna adaptor
• Mounting hardware
• Bluetooth / Wi-Fi antenna
• Reset pin
• Quick manual
