Dynavision Rearview Reverse Camera Hole Mount

Dynavision Universal Car Reversing Camera - Hole Mount

The Dynavin CAMUNI-002HD Lite is a high-resolution, flush-fit colour reverse camera designed for discreet, factory-style mounting into vehicle panels or bumper trim. Supporting both high-definition AHD (Analogue High Definition) and standard NTSC video formats, it delivers exceptional image sharpness during the day and enhanced low-light clarity at night across modern HD displays and traditional aftermarket head units.

Requiring only a compact 9 mm drill hole for installation, this hole-mount camera sits neatly for a sleek, integrated look. It features a 1/3-inch CMOS sensor chip and an ultra-wide 170-degree lens to eliminate blind spots behind your vehicle. The rugged IP67 waterproof, dustproof, and shockproof housing includes anti-fog optics to ensure reliable performance in all weather conditions. Supplied complete with a 6-metre extension cable, cable pull-through aid, and disassembly lever, it seamlessly connects to Dynavin head units or virtually any aftermarket display with an RCA or AHD video camera input.

Key Features & Applications:

• Flush Hole-Mount Design: Fits neatly into a small 9 mm panel hole for a subtle, OEM-style installation.
• Selectable Video Formats: Compatible with both high-definition AHD and standard NTSC display inputs.
• Selectable Parking Guide Lines: Integrated distance guide lines can be toggled on or off during setup to suit your preference.
• Ultra-Wide Field of View: 170-degree horizontal coverage provides comprehensive visibility of low-lying obstacles, curbs, and tow bars.
• Weatherproof & Shockproof: IP67 sealed body prevents water ingress, dust contamination, and fogging in extreme conditions.
• Dual Camera Setup Ready: Can be integrated alongside a front-view camera on screens with a single camera input when paired with the optional Dynavin DVN-V2 Camera Changeover Relay.

Specifications:

• Model: CAMUNI-002HD Lite
• Switchable Resolution: 1280 x 720 / 720 x 480 (Wide Angle View)
• Picture Output Mode: AHD / NTSC
• CMOS Sensor: 1/3" CMOS
• Lens Field of View (FOV): Horizontal 170°, Vertical 90°
• Weather Resistance: IP67 waterproof, dustproof, and shockproof
• Mounting Hole Required: 9 mm (approx.)
• Camera Body Dimensions: 27 x 28.5 x 31 mm (W x H x D, approx., cable not included)
• Configuration Options: Wire loop for selectable parking guide lines; wire loop for AHD format toggle; reverse trigger wire available where needed

Inclusions:

• Dynavision Hole-Mount Reverse Camera
• 6 m Extension Cable
• Power Adaptor Cable
• Video Output Cable
• Adhesive Mounting Pad
• Installation Kit (including cable pull-through aid and disassembly lever / spudger)

Optional Accessories:

Looking to add a front view camera as well? Combine this camera with the Dynavision Universal Front Camera and the Dynavin DVN-V2 Rear View Camera Changeover Relay to automatically switch between front and rear video feeds on a single display input.
