Dynavision Rearview Reverse Camera Flat Bracket Mount

Dynavision Universal Car Reversing Camera - Flat Bracket Mount

The Dynavin CAMUNI-001HD Lite is a high-resolution colour reverse camera designed to deliver superior rearward visibility, crisp image sharpness during the day, and enhanced brightness in low-light conditions. Supporting both high-definition AHD (Analogue High Definition) and standard NTSC video formats, it offers seamless compatibility across modern high-definition displays and traditional aftermarket head units.

Built around a 1/3-inch CMOS sensor chip and an ultra-wide 170-degree viewing lens, this camera eliminates blind spots directly behind your vehicle to assist with safe parking and reversing. The durable IP67-rated waterproof, dustproof, and shockproof housing features an anti-fog lens to maintain optical clarity in harsh weather conditions. Complete with a 6-metre extension harness, a cable pull-through aid, and a disassembly lever, it is ready to connect to Dynavin head units or virtually any aftermarket stereo with a standard RCA or AHD camera input.

Key Features & Applications:

• Selectable Video Formats: Switch between high-definition AHD and standard NTSC signal modes to suit your monitor input.
• Selectable Parking Guide Lines: On-screen parking assistance lines can be enabled or disabled during installation depending on your display preferences.
• Ultra-Wide Field of View: 170-degree horizontal coverage ensures comprehensive visibility of low-lying obstacles, curbs, and pedestrians.
• Rugged Weatherproof Construction: IP67 sealed body with anti-fog optics protects against water ingress, dust, and road vibration.
• Dual Camera Setup Ready: Can be combined with a front-view camera on displays with a single camera input when paired with the optional Dynavin DVN-V2 Camera Changeover Relay.

Specifications:

• Model: CAMUNI-001HD Lite
• Switchable Resolution: 1280 x 720 / 720 x 480 (Wide Angle View)
• Picture Output Mode: AHD / NTSC
• CMOS Sensor: 1/3" CMOS
• Lens Field of View (FOV): Horizontal 170°, Vertical 90°
• Weather Resistance: IP67 waterproof, dustproof, and shockproof
• Camera Body Dimensions: 23 x 23 x 27 mm (W x H x D, approx., excluding bracket and cable)
• Harness Cable Diameter: 4 mm (approx.)
• Mounting Bracket: Bendable flat bracket for flexible angle adjustment
• Configuration Options: Wire loop for selectable parking guide lines; wire loop for AHD format toggle; reverse trigger wire included where needed

Inclusions:

• Dynavision Reverse Camera
• 6 m Extension Harness Cable
• Power Adaptor Cable
• Video Output Cable
• Adhesive Mounting Pad
• Installation Kit (including cable pull-through aid and disassembly lever / spudger)

Optional Accessories:

Want to add a front-facing camera to your vehicle as well? Pair this camera with the Dynavision Universal Front Camera and the Dynavin DVN-V2 Rear View Camera Changeover Relay to automatically switch between front and rear video feeds on a single display input.
