SKU: V-2113-FR13WP FR 13 WP White - 4 Ohm

Visaton Speaker Driver - FR 13 WP - 4 Ohm Saltwater Resistant - White
Art. No. 2113

Characteristics and Sound Properties
Saltwater resistant 13 cm (5") full-range driver with moulded plastic cone, plastic basket and grille. Absolutely corrosion-resistant and waterproof due to encased magnet and silicon-coated leads. Clear-cut high-range output. White colour.

Typical applications:-
- Outdoor PA systems
- Loudspeaker for solariums and damp locations
- Boats, ships and open vehicles

Attributes:-
- Suitable for outdoor applications
- Seawater proof
- Functionally at low temperature according to EN 60068-2-1 (-40 °C; 96 h)
- Up to the standards of the Germanischer Lloyd (requirements for electrical equipment/low temperature)
- Plastic: ASA (UL 94:HB; UV-/weather-proof)
- Ball-resistant

Technical Specifications

Rated power	40 W
Maximum power	60 W
Nominal impedance Z	4 Ohm
Frequency response	70–16000 Hz
Mean sound pressure level	85 dB (1W/1m)
Opening angle (-6 dB)	69°/4000 Hz
Excursion limit	± 2.5 mm
Resonance frequency fs	100 Hz
Magnetic induction	0.85 T
Magnetic flux	210 uWb
Height of front pole-plate	4 mm
Voice coil diameter	20 mm
Height of winding	5 mm
Cutout diameter	112 mm
Net weight	0.29 kg
DC resistance Rdc	3.8 Ohm
Mechanical Q factor Qms	2.49
Electrical Q factor Qes	2.19
Total Q factor Qts	1.17
Equivalent volume Vas	4.4 litres
Effective piston area Sd	78 cm2
Dynamically moved mass Mms	4.8 grams
Force factor Bxl	2.3 Tm
Inductance of the voice coil L	0.4 mH
Protective System	IP 65 / IP 67 *)
Connections	4.8 x 0.8 mm (+) 2.8 x 0.8 mm (−)
Colour	White
Temperature range	-40 ... 80 °C

*) IP protection class for front side when built into a sealed enclosure
