WS 13 E - 8 Ohm

Thumbnail Filmstrip of WS 13 E - 8 Ohm Images

    Purchase WS 13 E - 8 Ohm

    SKU: V-1053-WS13E WS 13 E - 8 Ohm

    $42.00 each
    Brand: Visaton
    Shipping Weight: 0.56 kg
    Quantity in Basket:  None







    Visaton Speaker Driver - WS 13 E - 8 Ohm Fullrange Driver
    Art. No. 1053

    Visaton WS13E - 8 Ohm Fullrange Driver.
    Visaton WS13E - 8 Ohm Full Range Driver.



    Characteristics and Sound Properties
    13 cm (5") fullrange driver with paper cone and elastic rubber surround. Can be used as a low-midrange driver too. Due to the special basket design especially suitable as replacement driver for many HiFi speakers.



    Technical Specifications

    Rated power 40 W
    Maximum power 60 W
    Nominal impedance Z 8 Ohm
    Frequency response
    (fu: Lower cut-off frequency depending on cabinet)
    fu-12000 Hz
    Mean sound pressure level 86 dB (1W/1m)
    Opening angle (-6 dB) 65°/4000 Hz
    Excursion limit ± 7.5 mm
    Resonance frequency fs 83 Hz
    Magnetic induction 1 T
    Magnetic flux 250 µWb
    Height of front pole-plate 4 mm
    Voice coil diameter 20 mm
    Height of winding 5.5 mm
    Cutout diameter 113 mm
    Net weight 0.34 kg
    DC resistance Rdc 7.7 Ohm
    Mechanical Q factor Qms 3.52
    Electrical Q factor Qes 1.56
    Total Q factor Qts 1.08
    Equivalent volume Vas 7.7 litres
    Effective piston area Sd 86.5 cm2
    Dynamically moved mass Mms 5.1 grams
    Force factor Bxl 3.6 Tm
    Inductance of the voice coil L 0.8 mH

    Box Suggestions:
    33 Litre (closed box) -> Qtc: 1.2
    17 Litre (closed box) -> Qtc: 1.3
    11 Litre (closed box) -> Qtc: 1.4

    45 Litre (BR box @ fb= 47 Hz), fu= 35 Hz
    30 Litre (BR box @ fb= 54 Hz), fu= 43 Hz
    15 Litre (BR box @ fb= 67 Hz), fu= 60 Hz





    Driver Dimensions

    Loudspeaker Driver Dimensions and Measurements - all dimensions in mm (approx.)
    Loudspeaker Driver Dimensions and Measurements - all dimensions in mm (approx.)



    Frequency and Impedance Response

    Loudspeaker Frequency and Impedance Response Graph
    Loudspeaker Frequency and Impedance Response Graph



    Directivity Pattern

    Loudspeaker Directivity Pattern (on and off axis response)
    Loudspeaker Directivity Pattern (on and off axis response)
