Kienzle MCR 1120 DAB+ Bluetooth Car Radio with USB / AUX / AM / FM / DAB+

Description
The Kienzle MCR 1120 car radio is an ideal audio solution for classic, commercial, and modern vehicles requiring digital DAB+ radio, AM / FM reception, and Bluetooth telephone connectivity with music streaming. Featuring an understated OEM-style matte black finish, this unit blends seamlessly into a wide variety of dashboards. The mechaless single-DIN design supports a wide range of digital media formats from dual USB drives and AUX inputs to wireless Bluetooth streaming, delivering clean high-fidelity audio output.

Key Features:

Multi-Source Connectivity: Single-DIN mechaless car radio with AM / FM, DAB+, dual USB ports, dual AUX inputs, and Bluetooth V5.1.
Integrated Bluetooth: Supports hands-free telephone calls and A2DP audio streaming, with memory for up to 3 paired mobile phones (1 active at a time).
iPhone Compatibility: USB MFi (Made for iPhone) compatible via USB cable connection.
Clean OEM Appearance: Matte black fixed front panel with an easy to read LCD display and logical button layout.
Dual USB & AUX Inputs: Features 1x front USB and 1x rear USB, along with 1x front 3.5 mm AUX and 1x rear RCA AUX with adjustable input sensitivity.
High-Power Audio Output: Integrated 4-channel power amplifier producing 4 x 45 W maximum power output (4 x 20 W RMS).
Customisable Display: Adjustable button illumination (white or amber) with dimming control.
Preamp Outputs: 5-channel RCA preamp output (front, rear, and dedicated subwoofer) with 2V line-out level.

Technical Specifications:

Radio Tuner: FM (18 presets), AM (12 presets), and DAB+ (18 presets) with Auto Store. AM band can be enabled in settings if required.
Tuner Features: RDS functionality and switchable tuner region settings (Australia, USA, Europe, and others).
DAB+ Digital Radio: DAB+ digital reception (DAB aerial not included).
Audio Formats & USB Playback: MP3 and WMA file support via USB drives up to 32 GB maximum capacity.
MP3 Display & Search: ID3 tag display (track, artist, album), folder display, and song / file / character search.
Equaliser & Tone Control: 3-band equaliser (adjustable Q factor, frequency, and gain), 5 preset EQ modes, Fader, Balance, and Loudness controls.
USB Charging Output: 5V DC @ 1.5A fast charging port.
Microphone Options: Selectable internal front panel microphone or supplied external microphone.
System Controls: 12 / 24 hour clock, button confirmation beep (on / off), password protection option, Logic On / Off, and Last Position Memory.
Operating Voltage: 12V DC system voltage.
Connections: Standard rear ISO terminals (wiring harness adapters not included).
Chassis Dimensions: Approx. 187 x 57 x 94 mm (W x H x D).
Unit Weight: Approx. 0.65 kg.

Suggested Uses & Applications:

Upgrading audio systems in classic 1980s and 1990s vehicles (such as Mercedes-Benz, BMW, Porsche, and VW) requiring an factory-style matte black appearance.
Fitting digital radio and Bluetooth calling into commercial, agricultural, or utility vehicles with limited rear dashboard clearance.

Installation & Fitment Warnings (Please Read Before Ordering & Installation):

AM Tuner Activation Note: The AM tuner band is disabled by default in factory settings. If AM radio reception is required, enable the AM band via the radio's setup menu during initial configuration.
DAB+ Aerial Requirement: A DAB+ digital antenna is not included with the unit. A compatible active or passive DAB+ aerial (on-glass or fender mount) must be fitted to receive digital radio stations.
ISO Wiring Harness: The rear panel features built-in ISO terminals. Vehicle-specific ISO adapter harnesses and power / speaker looms are not included and should be selected according to your vehicle's wiring configuration.
Shallow Mounting Depth: Features a shallow mounting depth of approximately 94 mm, making it ideal for vehicles with tight dashboard clearance or rear wiring space restrictions.

In the Box:

Kienzle MCR 1120 DAB+ main head unit
External hands-free microphone
Auxiliary input cable
DIN installation cradle and release tools
Mounting screws
Instruction manual (English included)
