AL 130 - 8 Ohm

Thumbnail Filmstrip of AL 130 - 8 Ohm Images

    Purchase AL 130 - 8 Ohm

    SKU: V-1301-AL130 AL 130 - 8 Ohm

    $295.00 each
    Brand: Visaton
    Quantity in Basket:  None







    Visaton Speaker Driver - AL 130 - 8 Ohm Bass Midrange
    Art. No. 1301

    Visaton AL130 - 8 Ohm.
    Visaton AL130 - 8 Ohm.



    Characteristics and Sound Properties
    13 cm (5") High-End low midrange driver with stiff, anodised aluminium cone, solid aluminium die-cast basket and elastic rubber surround. Extremely low electrical and mechanical losses due to vented pole plate and vented damper. Capton voice-coil and impedance control ring. Extremely long cone displacement due to long stroke voice coil. Suitable as low-midrange driver for 3-way High-End applications up to 5000 Hz.



    Technical Specifications

    Rated power 60 W
    Maximum power 90 W
    Nominal impedance Z 8 Ohm
    Frequency response
    (fu: Lower cut-off frequency depending on cabinet)
    fu-8000 Hz
    Mean sound pressure level 87 dB (1W/1m)
    Dispersion angle (-6 dB) 94°/4000 Hz
    Excursion limit ± 8.5 mm
    Resonance frequency fs 43 Hz
    Magnetic induction 0.95 T
    Magnetic flux 450 µWb
    Height of front pole-plate 6 mm
    Voice coil diameter 25 mm
    Height of winding 18 mm
    Cutout diameter 115 mm
    Net weight 1 kg
    DC resistance Rdc 5.6 Ohm
    Mechanical Q factor Qms 4.37
    Electrical Q factor Qes 0.42
    Total Q factor Qts 0.38
    Equivalent volume Vas 13 litres
    Effective piston area Sd 79 cm2
    Dynamically moved mass Mms 9 grams
    Force factor Bxl 5.6 Tm
    Inductance of the voice coil L 0.9 mH





    Recommended Cabinet Sizes

    Volume / Principle BR Port fb fc / QTC
    5 litre / closed - - 81 Hz/0.72
    10 litre / bass reflex BR 6.8 48 Hz -
    20 litre / bass reflex BR 19.24 38 Hz -
    fb = Enclosure resonance (bass reflex system)
    fc = System resonance (sealed box system)
    QTC = The system's Q at resonance (fc)



    Driver Dimensions

    Loudspeaker Driver Dimensions and Measurements- all dimensions in mm (approx.)
    Loudspeaker Driver Dimensions and Measurements - all dimensions in mm (approx.)



    Frequency and Impedance Response

    Loudspeaker Frequency and Impedance Response Graph
    Loudspeaker Frequency and Impedance Response Graph



    Directivity Pattern

    Loudspeaker Directivity Pattern (on and off axis response)
    Loudspeaker Directivity Pattern (on and off axis response)



    Waterfall Spectrum

    Loudspeaker Waterfall Spectrum Chart
    Loudspeaker Waterfall Spectrum Chart
