Coaxial W124 Speakers CX-120 120mm 5 Inch 4 Ohm

Dietz CX-120 2-Way Coaxial Speakers 120mm 5 Inch 80W 4 Ohms

The Dietz CX-120 coaxial speaker set is a high-performance audio upgrade specifically designed for vehicles requiring a 120 mm round speaker basket. Most notably recognised as the ideal direct-fit replacement for the front dashboard speakers in the Mercedes-Benz W124 E-Class (1985 - 1995), these speakers feature built-in spring mounting clips that allow them to snap cleanly into the factory dash apertures without requiring custom brackets or dashboard modifications. We have optional adaptor rings for the rear W124 speakers.

High-Fidelity Coaxial Sound

Equipped with a specially coated woofer cone for rich mid-bass response and a 30 mm Mylar dome tweeter for crisp, clear highs, the CX-120 delivers a dramatic improvement in clarity over tired, aging factory speakers. Handling up to 80 Watts peak power, they are perfectly matched to operate efficiently on both original factory radios and modern aftermarket head units.

Important Compatibility Check:

While this product is engineered for specified factory fitments, classic and vintage vehicles often feature subtle mid-year production changes, regional options, or modifications by previous owners. We strongly recommend checking your existing factory wiring, speaker size, and physical mounting clearance before placing your order to ensure complete compatibility with your specific vehicle.

Specifications:

• Speaker Type: 2-Way coaxial loudspeaker system
• Basket Size: 120 mm (approx. 4.75 - 5 inch Euro DIN basket)
• Mounting Style: Integrated spring mounting clips for drop-in installation in Mercedes W124 dash slots
• Power Handling: 40 Watts RMS, 80 Watts Max Power
• Impedance: 4 Ohms
• Frequency Response: 97 Hz - 20,000 Hz
• Tweeter: 30 mm Mylar membrane dome tweeter
• Woofer Cone: Coated composite cone for smooth mid-range performance
• Mounting Depth: 50.5 mm (approximate)
• Cutout Diameter: 110 mm (approximate)

Package Contents:

• 1 Pair of Dietz CX-120 loudspeakers (2 pieces)
• 4 Crimp connector terminals
