SKU: RetroSound-Window-Aerial-WPA2 Amplified AM FM Window Antenna WPA-2

Amplified AM / FM Window Antenna

This amplified AM/FM window antenna is a great solution for anyone who doesn't want to install a standard fender-mount antenna. Suitable for almost any AM/FM radio. Upgraded model replacing the WPA1.

The RetroSound WPA2 enhanced amplified hide-away antenna is a great solution for anyone who doesn't want to install a standard fender-mount antenna. The WPA2 installs in seconds using a standard antenna plug and your radio's power antenna wire. This antenna uses magnetic field circuitry for enhanced radio reception. It can be installed almost anywhere thanks to the supplied 105-inch antenna lead and power wire.

Installation

• Place the main body of the WPA2 as high in the dash as possible or using the adhesive backing secure to the upper windshield or rear glass. Avoid placing it near any high-current wiring. If you want to test it first, use tape before sticking permanently.
• Glass installation: Clean the mounting area with an alcohol wipe. Using a lint-free rag, clean any residue off the window. Peel backing off the adhesive strip and press firmly to the glass surface. Be careful not to press too hard on windshield applications.
• Route the antenna cable with the thin black power wire to your radio location. Connect the thin black wire to a 12-volt ignition source or the blue power antenna output wire of your radio.
• Connect the male antenna plug into the female antenna receptacle of your radio. Some radios may need an adaptor (not needed for Retro Radios).
