RetroSound 4x10 Inch Dual Voice Coil Speaker R-410N

RetroSound R-410N 4 x 10 Inch 90 Watt DVC - Dual Voice Coil Speaker

Designed and tooled from the ground up, the RetroSound series of premium dash speakers meets the demanding needs of today's high-performance amplifiers while maintaining exact factory dimensions for original location mounting. Fully compatible with all modern digital music sources, the N Series features an ultra-thin mounting profile to fit virtually any classic vehicle application. This speaker utilises an advanced neodymium magnet structure that is five times more powerful than standard speaker magnets. This allows for a substantial reduction in mounting depth while maintaining excellent power handling, heat dissipation, and bass response.

The Dual Voice Coil Advantage

The innovative Dual Voice Coil (DVC) design allows you to connect both the left and right stereo channels from your radio directly to one single speaker. This provides a full, rich stereo mix and maximum sound output for single-speaker applications. These speakers are typically used in vintage and classic cars that feature only a single speaker location in the dashboard or rear deck area. A single dual-tweeter DVC speaker provides a vastly superior, fuller sound compared to a standard mono or single voice coil speaker.

8 Ohm Wiring Option for Vintage Radios

Because this speaker features dual 4 Ohm voice coils, it can be wired in series to create an 8 Ohm impedance load. This makes it an ideal upgrade if you are retaining an original vintage factory radio that requires an 8 Ohm or 10 Ohm speaker output, preventing damage or overheating to your original head unit. The 8 Ohm wiring kit is included to make this series connection quick and simple.

Important Fitment Advisory: Measure Before Ordering

While this speaker is engineered to fit standard 4 x 10 inch factory dash apertures, classic cars often feature subtle manufacturing variations, mid-year production changes, or modifications by previous owners (such as altered brackets, replaced dash tops, or custom wiring). We strongly advise measuring your physical mounting area, depth clearance, and screw hole spacing prior to ordering to confirm exact compatibility with your vehicle.

Specifications:

• Power Handling: 90 Watts RMS, 160 Watts Max Power (across both coils)
• Impedance: Dual 4 Ohms (can be wired in series for 8 Ohms)
• Size: 4 x 10 inch Dual Voice Coil full-range speaker
• Frequency Response: 43Hz - 21kHz (SPL @ 1W / 1m)
• Sensitivity: 87dB
• Tweeters: Flush-mount dual silk dome tweeters for smooth, natural highs
• Output: True stereo mix from a single speaker location
• Cone: Rigid pulp composite cone for accurate mid-bass
• Surround: Santoprene rubber surround for smooth, natural sound and durability
• Mounting Depth: Ultra-thin 2.32 inch (59 mm) mounting depth (approximate)
• Magnet: Dip-cut neodymium magnet structure for extended pole piece excursion
• Note: Grille not included
• Basic mounting hardware and wires included
