    Visaton - Waveguide WG148R
    Art. No. 5176

    Visaton Waveguide WG 148 R
    Visaton Waveguide WG 148 R



    Description
    14.8 cm waveguide of high-quality plastic for 25 mm tweeters. The exponential enlargement provides a high sound pressure level gain in the lower high frequency range, which discharges the tweeter. In addition, the focus and the coupling to a woofer are improved, because the sound generation planes move closer together.

    For fixation of the tweeter on the waveguide 4 pieces M4 screws (length approx. 10 mm) are added.

    This waveguide is suitable for: G25FFL - 8 Ohm; KE25SC - 8 Ohm



    Technical Specifications

    Cutout diameter 115 mm
    Net weight 100 g
    Cutout diameter (tweeter) D = 38 mm



    Dimensions

    Dimensions and Measurements - all dimensions in mm (approx.)
    Dimensions and Measurements - all dimensions in mm (approx.)
