B 200 - 6 Ohm

Thumbnail Filmstrip of B 200 - 6 Ohm Images

    Purchase B 200 - 6 Ohm

    SKU: V-1350-B200 B 200 - 6 Ohm

    $375.00 each
    Brand: Visaton
    Quantity in Basket:  None







    Visaton Speaker Driver - B200 - 6 Ohm High End Full Range Loudspeaker
    Art. No. 1350

    Visaton B200 6 Ohm.
    Visaton B200 6 Ohm



    Characteristics and Sound Properties
    20 cm (8") High-end full-range loudspeaker. These high-end speakers stand out because of their high degree of sensitivity and extremely well-balanced frequency response free of noticeable deviations. This is achieved by using a very light-weight paper cone, a fabric surround and an optimised driver equipped with a 25 mm voice coil (aluminium wire) which makes optimum use of the magnetic field in the air gap. The capton voice coil carrier is vented. The sturdy aluminium diecast basket is not only optically appealing but, thanks to its rear-venting openings, ensures that physical losses are minimised. Distortion is suppressed to a very low, uniform level.

    The B 200 is ideally suited to use in high-quality, powerful single-band speakers, where the cabinet design need not be restricted to classic, fully enclosed or vented cabinets, but more exotic alternatives like horns or open baffles can be used to create amazing results.



    Technical Specifications

    Rated power 40 W
    Maximum power 70 W
    Nominal impedance Z 6 Ohm
    Frequency response
    (fu: Lower cut-off frequency depending on cabinet)
    fu-18000 Hz
    Mean sound pressure level 96 dB (1W/1m)
    Dispersion angle (-6 dB) 48°/4000 Hz
    Excursion limit ± 3.5mm
    Resonance frequency fs 40 Hz
    Magnetic induction 1.2 T
    Magnetic flux 755 µWb
    Height of front pole-plate 8 mm
    Voice coil diameter 25 mm
    Height of winding 4 mm
    Cutout diameter 190 mm
    Net weight 2.16 kg
    DC resistance Rdc 5.0 Ohm
    Mechanical Q factor Qms 8.39
    Electrical Q factor Qes 0.83
    Total Q factor Qts 0.75
    Equivalent volume Vas 102 litres
    Effective piston area Sd 214 cm2
    Dynamically moved mass Mms 9.7 grams
    Force factor Bxl 3.9 Tm
    Inductance of the voice coil L 0.5 mH



    Recommended Cabinet Sizes

    Volume / Principle fc/QTC
    70 litre / closed 62 Hz/1.18
    100 litre / closed 58 Hz/1.10
    fc = System resonance (sealed box system)
    QTC = The system's Q at resonance (fc)



    Driver Dimensions

    Loudspeaker Driver Dimensions and Measurements - all dimensions in mm (approx.)
    Loudspeaker Driver Dimensions and Measurements - all dimensions in mm (approx.)



    Frequency and Impedance Response

    Loudspeaker Frequency and Impedance Response Graph
    Loudspeaker Frequency and Impedance Response Graph



    Directivity Pattern

    Loudspeaker Directivity Pattern (on and off axis response)
    Loudspeaker Directivity Pattern (on and off axis response)



    Waterfall Spectrum

    Loudspeaker Waterfall Spectrum Chart
    Loudspeaker Waterfall Spectrum Chart
